How to Choose a Pond Pump
How to Choose a Pond Pump: Flow Rate, Head Height & Sizing Guide
The wrong pond pump is one of the most common mistakes pond owners make — and one of the most expensive.
Too small, and your water turns cloudy and green because it's never properly circulated. Too large, and you're paying for power you don't need, and stressing your fish with too much current.
Getting the size right the first time saves you money and stops you buying twice. This guide walks through the four numbers that matter most: pond volume, turnover rate, head height and running cost.
One thing worth knowing before you buy: both Luponds pumps are asynchronous (fixed-speed) motors, which means either one can be paired with a Smart Controller to adjust flow from 10% to 100%, on a schedule, from an app or the handheld remote it comes with. It's easy to add later, but if you already know you want that flexibility, it's worth factoring into your setup from the start rather than as an afterthought.
The controller handles up to 1200W, which comfortably covers either Luponds pump — the 13,000 LPH draws 130W and the 30,000 LPH draws 660W. Because it reduces the pump's actual motor speed rather than restricting the outlet, running it slower overnight or through cooler months genuinely cuts power use, and also means less noise and less wear on seals and bearings. Step 7 below covers this in more detail.
In This Guide
1. Work Out Your Pond Volume
Every pump decision starts with one number: how many litres of water you're moving.
If you haven't worked this out yet, use our free Pond Volume Calculator. Enter your pond's dimensions and it gives you the volume in litres. Every other step in this guide builds on that number.
2. Work Out Your Turnover Rate
Turnover rate is how many times your pump cycles the whole pond through filtration in one hour. Here's a simple starting point:
| Pond Type | Recommended Turnover |
| Ornamental / goldfish pond | Full volume once per hour (1x) |
| Koi pond | Full volume 1.5–2x per hour |
| Water wall or water blade feature | Sized to spillway width, not pond volume — see Step 4 |
Koi ponds need more turnover because koi produce more waste than goldfish.
One tip: stocking levels aren't fixed. Koi keepers often start with more fish than the pond needs long-term, then thin them out as they grow. Goldfish numbers tend to come from breeding instead. Either way, size your pump for the fish you'll have once they're fully grown — not just what's in the pond today.
3. Account for Head Height
A pump's flow rate (LPH) is only accurate when water isn't being lifted at all. The moment you push water uphill — into a raised filter, up a waterfall, or up the face of a water wall — flow drops.
This vertical lift is called head height. Every pump has a maximum head height, which tells you how far it can lift water before flow drops to zero.
Rule of thumb: pick a pump with a maximum head height comfortably above what you actually need. Running a pump near its limit strains the motor and delivers less real-world flow than the headline number suggests. If you're feeding a raised filter or tall feature, check the manufacturer's flow-at-head chart rather than relying on the maximum LPH figure alone.
4. Match the Pump to the Job
| Application | What to Prioritise |
| Biological / pressure filtration | Turnover rate matched to pond volume and bioload — see our Pond Filtration Selection Guide |
| Waterfall or cascade | Flow rate at your actual head height, not the maximum LPH figure |
| Water wall / water blade spillway | Flow rate sized to spillway width, plus head height to the top of the wall |
| Fountain | Flow rate matched to nozzle size, plus head height to the fountain head |
| UV clarifier | Flow rate within the UV unit's rated range — too fast reduces clarifying performance |
5. Submersible vs Dry (External) Installation
Most pond pumps sold in Australia, including the Luponds range, can be installed either way — fully submerged, or dry with a gravity feed.
A submerged pump is quieter, simpler to install, and usually carries a longer warranty.
A dry-installed pump is easier to reach for maintenance, but it must sit lower than the water surface, since it isn't self-priming. Check the warranty terms for each installation type before you decide — they often differ.
6. Compare Pump Options by Flow Rate
DIYMegaStore stocks pond pumps across Luponds, OASE and PondMAX — from small water features to large commercial installations. Where a range covers several models, each model number below links straight to its own product page.
| Brand & Series | Flow Rate / Head | Best For |
| Luponds Energy Efficient 13,000 LPH | 13,000 LPH / 5.0m head, 130W | Small to medium ponds, waterfalls, smaller water walls. IPX8, ceramic shaft, 2yr warranty submerged. Pairs with our Smart Controller for adjustable, scheduled flow |
| Luponds Multi Use 30,000 LPH Commercial Grade | 30,000 LPH / 8.0m head, 660W | Large ponds, commercial water walls, high-volume filtration. Oil-free magnetic drive (fish-safe), ceramic bearings, IPX8. Also pairs with the Smart Controller |
| PondMAX Filtration/Waterfall Pumps: PU3500, PU5500, PU7500, PU12500 |
3,500–12,500 LPH | Filtration and waterfall feeds across small-to-mid ponds |
| PondMAX EVO II Submersible: EV11200, EV13600 |
11,200–13,600 LPH / 6.5–7.0m head | Large koi ponds and waterfalls needing high flow with anti-burnout and soft-start protection |
| PondMAX EVO II Low Voltage (12V DC): EV1910-DC, EV2910-DC, EV3910-DC, EV4910-DC |
1,800–4,600 LPH / 2.1–5.1m head | Small fountains and water features where children or pets may be near the water — 12V low-voltage design, solar compatible on smaller models |
| OASE AquaMax Eco Classic: 5500, 8500, 11500, 14500, 17500 |
5,500–17,500 LPH | Straightforward, energy-conscious filtration for medium to large ponds |
| OASE AquaMax Eco Premium Dual Inlet: 9000, 13000, 16000, 17000, 21000 |
9,000–21,000 LPH / 4.5–6.0m head | Large koi ponds needing high turnover, app control and dual-inlet flexibility for a skimmer or satellite filter |
| OASE AquaMax Eco Premium 12000 (12V) | 11,400 LPH / 3.2m head | Swimming ponds and natural pools where people are in the water — low-voltage design for safety |
| OASE AquaMax Eco Expert: 21000, 36000, 44000 |
21,000–44,000 LPH / 8.0–9.5m head | Commercial and large-scale ponds, demanding filter systems, big watercourses and waterfalls needing serious lift |
A note on PondMAX EVO II: the EV11200/EV13600 models are mains-voltage submersible pumps built for large koi ponds and waterfalls, with anti-burnout and soft-start protection. The EV1910-DC to EV4910-DC models are a separate low-voltage (12V) range for smaller fountains and features — the same safety logic as OASE's 12V Premium pump below, making them a sensible choice anywhere children or pets are likely to be near the water.
Which OASE series is right for you? The three ranges are aimed at different jobs, not just different flow rates:
| Series | Positioning |
| Eco Classic | The straightforward, no-frills option. Reliable filtration and waterfall pumping without the smart-control extras — a solid choice if you just want a dependable pump at a lower price point. |
| Eco Premium | Adds a patented second (dual) inlet so you can run a surface skimmer or satellite filter off the same pump, plus OASE Control app compatibility, seasonal flow adjustment and frost protection to -20°C. The 12V variant swaps standard mains voltage for a low-voltage circuit, purpose-built for swimming ponds and natural pools where people are in the water. |
| Eco Expert | The commercial-grade tier. Stainless steel housing, much higher head height (8.0–9.5m) and flow up to 44,000 LPH, with electronic Seasonal Flow Control for up to 30% energy savings. Built for demanding filter systems, large watercourses and waterfalls — the choice once you're beyond what Classic or Premium can lift or move. |
Browse the full range on our Pond Pumps category page, or see our Pond Filtration Selection Guide if you need a filter to go with it.
7. Running Costs and Energy Efficiency
A pond pump usually runs 24 hours a day, every day of the year. That makes it one of the biggest ongoing power costs in a pond system.
An oversized or poorly matched pump can add hundreds of dollars a year to your power bill compared to a correctly sized one. Two ways to cut costs without hurting water quality:
| • | Choose the smallest pump that still meets your turnover and head height needs — don't buy extra capacity "just in case" |
| • | Fit a Smart Controller to an existing fixed-speed pump, such as either Luponds model above. It lets you reduce flow overnight or in cooler months without buying a new pump — and because it slows the motor down rather than just restricting the outlet, the savings are real. It comes with both a WiFi app and a handheld remote, so you're never stuck without a way to adjust it |
See the note above on pairing a Luponds pump with the Smart Controller if you're weighing this up before you buy.
8. Installation and Safety Basics
| • | Run the pump through a Residual Current Device (RCD) rated at 30mA or less, as required under AS/NZS rules |
| • | Keep the electrical connection dry, at least 2 metres from the pond edge, with a drip loop in the cable |
| • | Never run a pump dry — it will damage the motor and void the warranty |
| • | Sit the pump on a raised, stable surface, clear of mud and sludge — not directly on the pond floor |
| • | Clean the impeller and intake screen at least once a month. A dirty impeller is the most common cause of pump failure, and it isn't covered under warranty |
Not sure which pump suits your setup? Call us on 1300 238 288 or email support@diymegastore.com.au with your pond volume, head height and what you're running. We'll help you match the right pump — no obligation.
Frequently Asked Questions
What size pump do I need for my pond?
Start with your pond volume in litres, then match it to a turnover rate: once per hour for an ornamental or goldfish pond, 1.5–2 times per hour for a koi pond. Use our Pond Volume Calculator to get your litres, then check the pump's flow rate at your actual head height — not just its maximum LPH figure.
Is it better to oversize or undersize a pond pump?
Slightly oversizing is generally safer than undersizing, since inadequate turnover leads to poor water quality and algae problems. But going too big wastes power and can create too much current for fish. Aim to match your actual needs rather than simply buying the biggest pump available.
What's the difference between flow rate and head height?
Flow rate (LPH) is how much water the pump moves. Head height is how far up it can lift that water. A pump's maximum LPH is only reached at zero head height — flow drops the further you push water uphill. Always check performance at your actual lift, not just the headline number.
Should I choose a submersible or an external (dry-installed) pump?
Most modern pond pumps, including the Luponds range, can do either. Submersible installation is quieter and simpler, and often carries a longer warranty. Dry installation is easier to service, but the pump must sit lower than the water surface, since it relies on gravity feed rather than self-priming.
How can I reduce my pond pump's running costs?
Choose the smallest pump that still meets your turnover and head height needs, and consider fitting a Smart Controller to an existing fixed-speed pump. It lets you schedule reduced flow overnight or in cooler months, and because it slows the motor down rather than restricting flow mechanically, the savings are genuine.
Do I need a different pump for a water wall than for a pond?
Yes, the sizing calculation is different. Water walls and water blade spillways need flow matched to the width of the spillway rather than pond volume, plus head height to the top of the wall. The same pump ranges (Luponds, OASE, PondMAX) cover both jobs.
How often should I clean my pond pump?
At least once a month. Clean the intake screen and impeller chamber to clear debris and buildup. A dirty impeller is the most common cause of overheating and premature pump failure, and this kind of damage isn't covered under warranty.
Can a pond pump run 24 hours a day?
Yes — pond pumps are built for continuous operation and should generally run 24/7 to keep water filtered and oxygenated. Turning a pump off overnight can let filter bacteria die back and water quality deteriorate. If you want to save power overnight, a variable speed controller is a better option than switching the pump off entirely.
